Communication
ports
|
| USB 1.1 and USB 2.0 compatible host interface |
| 2 serial channels for ccTalk or RS-232 |
| IIC extension port |
| I/O
ports
|
| 16 off Inputs (5V CMOS thresholds with 5V
pull-ups) |
| 8 off Switch inputs with power-down monitoring |
| 24 off Outputs (open drain up to 250mA each) |
| 4 off Outputs (open drain up to 3A each) |
| 8 off Outputs (5V CMOS) |
| 8 off Bi-directional lines (5V CMOS IP or
250mA OP) |
| 1 off Current sensed +12V output |
| 1 off DIL switch |
| Audio
|
| 20W class D amplifier |
| Security
|
| Security Key function to protect against
piracy |
| Processor with real time clock and battery
backup (greater than 60 days hold up time) |
| Monitoring of eight switch inputs while
powered down |
| Indicators
|
| +3.3V, +5V, +12V and +24V supply LEDs |
| Four programmable LEDs |
| Connectors
|
| USB type B connector |
| General I/O: 40 way, 34 way, 16 way and
10 way headers |
| Hard disk - type power connector (+5V and
+12V input only) |
| Communication ports: 26 way header |
| Audio in: 3 way 3.5mm jack socket |
| Memory
|
| 512K x 8 in two independent battery-backed
SRAM |
| 8K x 8 Bit EEPROM |
| Supported
operating systems
|
| Microsoft Windows 2000 / XP / XPe / CE |
| Linux |
| Power
supply
|
| Regulated +5V DC input, +24V delay output
supply |
| Dimensions
|
| 75mm x 211mm (2.95" x 8.3") |
