| ITEM |
CONTENT |
| CPU |
VIA Eden
V4 / C7-D |
| System
Chipset |
VIA CN700+VT8237R+ |
| Graphic
Processor |
VIA Uni Chrome
Pro IGP |
| Display
Output |
1 Analog VGA
Output
1 18 / 24-bit LVDS Output |
| System
Memory |
1 DDR2-533
DIMM up to 1GB |
| Ethernet
NIC |
2 10 / 100
Mbps On-board |
| Audio |
5.1-Channel
AC97 On-board |
| Rear
IO Port |
2 PS / 2 Ports
1 VGA Port
1 RS232 Port
2 RJ45 Ports
4 USB 2.0 Ports
3 Audio Jacks (Line-in / Line-out / MIC)
1 LPT Port |
| Internal
IO Port |
2 USB Ports
2 RS232 Ports
1 RS232/422/485 Selectable Port |
| Storage |
2 SATA Ports
1 PATA Port |
| Expansion |
1 PCI 2.2 Slot |
| BIOS |
Award BIOS |
| Supported O.S |
MS Windows 2000 / XP / XPe / RedHat Linux |
| Board Size (LxW) |
170 x 170 mm |
| Power Supply |
20-pin ATX |
| Operating Temperature |
0 ~ 60 Degree C |
| Humidity |
10 ~ 85% Relative Non-condensing |
Dual Display
