| ITEM |
CONTENT |
|
CPU |
Intel u-FCPGA 478 Pentium M / Celeron M |
| System
Chipset |
Intel 915GM + ICH6M |
| Graphic
Processor |
Intel GMA900 IGP |
| Display
Output |
1 Analog VGA
Output
1 Dual channel LVDS Output (18-bit)
1 DVI Output |
| System
Memory |
2 DDR2-400 / 533 SODIMM up to 2GB |
| Ethernet
NIC |
Up to 3 PCIe Gbps On-board |
| Audio |
5.1-Channel AC97 On-board |
|
Rear
IO Port |
2 PS / 2 Ports
1 VGA Port
1 RS232 Port
3 Audio Jacks (Line-in / Line-out / MIC)
2 USB 2.0 Port
3 RJ45 Ports |
| Internal
IO Port |
4 USB 2.0 Ports
1 RS232 Port |
| Storage |
2 SATA Ports
1 PATA Port |
|
Expansion |
1 PCI 2.2 Slot |
| BIOS |
Award BIOS |
| Supported O.S |
MS Windows 2000 / XP / XPe / RedHat Linux |
| Board Size (LxW) |
170 x 170 mm |
| Power Supply |
20-pin ATX |
| Operating Temperature |
0 ~ 60 Degree C |
|
Humidity |
10 ~ 85% Relative Non-condensing |
Intel u-FCPGA 478 Pentium M / Celeron M
