| NEXUS-1500 |
| ¡@ |
 |
¡@ |
| ¡@ |
| Description |
The NEXUS-1500 Mini ITX motherboard
incorporates a Socket A processor socket that supports AMD
Geode NX series processors that support processor speed up
to 1.4GHz. With the SIS 741CX chipset, it delivers maximum
performance for demanding thin client or embedded applications
that require silent system operation. With a higher processor
speed and active cooling, it is best suited for demanding
applications such as graphics and point of sales systems.
The board comes with integrated chipset VGA and Ethernet controllers.
Optionally provided is a Realtek Gigabit Ethernet and daughter
cards for CRT2 / TMDS or LVDS / TV out interface. |
|
| ¡@ |
| Specification |
|
ITEM |
CONTENT |
| CPU |
Socket
A (462-pin) for AMD Geode, up to 1.4GHz (NX1250 = 667MHz,
NX1500 = 1GHz, NX1750 =1.4GHz) |
| System
Memory |
DDR
DIMM x 1, max. 1GB, DDR333 |
| System
Chipset |
SiS
741CX + SiS 964 |
| BIOS |
Award
4Mbit |
| Watchdog
Timer |
256
levels |
| SSD |
Optional
CF socket (on solder side via IDE2) |
| H/W
Monitor |
Yes |
| Expansion
Slot |
1
PCI, 1 Mini PCI, 1 MicroAGP |
| VGA
Controller |
SiS
741CX integrated for CRT |
| VGA
Memory |
Shared
memory; Max. 64MB |
| LCD
/ TV-out / DVI / CRT2 |
Optional
SiS 302LV MicroAGP card (IBA140-302) supports 18/24-bit
dual channel LVDS and TV out; Optional SiS 301 MicroAGP
card (IBA140-301) supports DVI/CRT2 interface |
| Controller |
SiS
964 built-in 10/100 and Optional Realtek RTL8110S-32 Gigabit
LAN |
| Chipset |
SiS 964, ITE 8705 2x IDE (UDMA33
/ 66 / 100), 1x FDD, 1x KB, 1x Mouse; 2x RS-232, 2x SATA |
| USB |
4 ports on board,
Pin header for 2 additional ports (USB 2.0) |
| Audio |
SiS 964 built-in audio + AC97
codec, SPDIF support; 2W+2W volume amplifier |
| Others |
1394, ATX power connector |
| Dimensions |
170mm x 170mm |
|
|
| ¡@ |
| Ordering Information |
|
ITEM |
DESCRIPTION
|
| NX-740 |
Socket A, SiS 741CX, Mini-ITX w/ 10/100 LAN,
SATA |
| NX-740F |
Socket A, SiS 741CX, Mini-ITX w/ 10/100 LAN,
Gigabit LAN, 1394, SATA |
| NX-140-302 |
SiS 302LV MicroAGP card for dual-channel
18/24-bit LVDS or TV out |
| NX-140-301 |
SiS 301 MicroAGP card for TMDS/DVI or
CRT2 |
| SM-5000-00 |
Mini-PCI NVRAM Security Card |
|
| ¡@ |
| * RoHS Compliant |
|
| ¡@ |
|
| ¡@ |
¡@ |
